Panel Meters





I)   STANDARD DIGITAL PANEL METERS

1 DIGITAL AC VOLTMETER
Model : M4W-AV
  Range: 0 to 500V
  With 3½ Digits, 0.55" LED
  Display Power Supply: 110V/220VAC
  Size: 96mm x 48mm

2 DIGITAL AC AMMETER
Model : M4W-AA
  Ranges: 0 - 60A, 0 - 100A, 0 - 200A, 0 - 400A, 0 - 800A, 0 - 1000A, 0 – 1999A
  With 3½ Digits, 0.55" LED Display
  Power Supply: 110V/220VAC
  Size: 96mm x 48mm
  Suitable for use with 60/5A, 100/5A, 200/5A, 400/5A, 800/5A, 1000/5A or 1999/5A  CT
  Other current ranges available on request

3 DIGITAL AC AMMETER
Model : MT4W-AA
  Range: 0 - 2500A /  0 - 3200A / 0 - 4000A / 0 - 5000A  /  0 - 6300A
  With 4 Digits, 0.55" LED Display
  Power Supply: 100 ~ 240VAC ± 10% Size: 96mm x 48mm
  Suitable for use with 2500/5A, 3200/5A,  4000/5A , 5000/5A, 6300A/5A CT

4 DIGITAL TACHOMETERS/PULSE METERS

Model : MP5W    or Equivalent
  Range: 1 to 99999 rpm
  With 5 Digits, 0.55" LED Display
  Power Supply: 100 to 240VAC
  Size: 96mm x 48mm
  Supplied with Autonics sensor PSN25-5DP

5 PRESET TACHOMETERS/PULSE METERS:

Model : MP5W     Preset, Triple Relay Output (H, GO, L
  5-Digits LED Indication

FEATURES:
* Power Supply : 100 to 240VAC ± 10%,  50/60Hz
* Measuring Range : 1 to 99999 rpm
* Measuring accuracy : 0.05% ± 1 digit
* Supplies power for external sensor.
* 13 various Function Modes
* Supplied with sensor PSN25-5DP
* Triple Output: High, GO, Low
* Meter without PSN25-5DP

6 PRESET TACHOMETERS/PULSE METERS:

Model : MP5W   or Equivalent
  5-Digit Preset, Quintuple (5) Relay Output (HH, H, GO, L, LL)

FEATURES:




Power Supply: 100 ~ 240VAC
Preset Setting & Range: 1 to 99999 rpm
Supplied with one standard sensor

II) Programmable Digital Panel Meters

1 DIGITAL AC AMMETERS
TYPE : MT4W-AA
  4-Digit LED Display with Data Hold Facility
  Power Supply: 100 ~ 240VAC ± 10%
  Selectable: RMS or AVG value display
  Accuracy: F.S. ± 0.3%
  Size: W96 x H48mm

  CT Input    Display
  30/5A   0 ~    30.00
  60/5A    0 ~    60.00
  100/5A    0 ~  100.0

  .

  150/5A    0 ~  150.0
  200/5A    0 ~  200.0
  300/5A     0 ~  300.0
  400/5A    0 ~  400.0
  600/5A    0 ~  600.0
  800/5A    0 ~  800.0
  1000/5A    0 ~ 1000
  1250/5A   0 ~ 1250
  1600/5A   0 ~ 1600
  2000/5A   0 ~ 2000
  2500/5A   0 ~ 2500
  3200/5A    0 ~ 3200
  4000/5A    0 ~ 4000
  6300/5A    0 ~ 6300

* Other CT inputs like 500/5, 1200/5, 1500/5, 3000/5, 8000/5A  can also be programmed.
* Also settable for CT secondary output of 1A.

2 DIGITAL AC VOLTMETER

Type:  MT4W-AV
  4-Digit Display with Data Hold Facility
  Power Supply: 100 ~ 240VAC ± 10%
  Selectable: RMS or AVG value display
   Accuracy: F.S. ± 0.3%
  Size: W96 x H48mm

  Voltage Set Range  Display
  0 ~ 150V   0~150
  0 ~ 300V   0~300
  0 ~ 500V   0~500
* Also suitable for 11KV/110V PT
* Other input ranges: 50V and 5V

3 DIGITAL DC AMMETER

Type:  MT4W-DA
  4-Digit Display with Data Hold Facility
  Power Supply: 100 ~ 240VAC ± 10%
  Accuracy: F.S. ± 0.1%
  Size: W96 x H48mm

  Input Ranges   Display
  0 ~    2mA    0 ~  100.0 or any display range
  0 ~  20mA    from -999 to 9999
  0 ~ 500mA
  0 ~    5A
* Good for analog signals

4 DIGITAL DC VOLTMETER

Type:  MT4W-DV
  4-Digit Display with Data Hold Facility
  Power Supply: 100 ~ 240VAC ± 10%
  Accuracy: F.S. ± 0.1%
  Size: W96 x H48mm

  Input Ranges   Display
  0 ~   50mV    0 ~  100.0 or any display range
  0 ~   5V/1V    from -999 to 9999
  0 ~   50V/10V
  0 ~  500V/100V
* Good for analog signals

  Optional Outputs Models:
* Relay Output
* NPN/PNP Open Collector + BCD O/P
* Open Collector Output + Current 4 – 20mA O/P
* Open Collector Output + RS485 Output
* Open Collector Output + Low Speed Serial Output

5 DIGITAL PULSE METER

Type:  MP5W-4N
  Range: 1 to 99999
  5-Digit LED Display with Data Hold Facility
  Power Supply: 100 ~ 240VAC ± 10%
  Accuracy: F.S. ± 0.1%
  Size: W96 x H48mm
  Supplied with Autonics Sensor PSN25-5DP

  NOTE:
  This list is subject to change without notice and goods being in stock.  The prices in the list are reference
  prices and not sale  prices.    Discounts/Multipliers  are  applicable.    The  delivery,  packing  and
  forwarding  charges are  extra.    All despatches are made on buyer’s risk and account.
