Magnetic Contactors (MC)



"TOGAMI" CONTACTORS:

SIZE MODEL CAPACITY AT RATED OPERATIONAL CURRENT  CONTACTS

380/440V
CURRENT Ith
      AC3 @ 380/440V

0A PAK-11J 4.5 KW/6  HP 9.5 A 20A 3P+1a
0.5 PAK-12J 5.5 KW/7.5HP 11.5A 26A 3P+1a
1.5 PAK-21J 11  KW/15 HP 22  A 32A 3P+1a1b
2.5 PAK-26J 20  KW/25 HP 35  A 50A 3P+2a2b
2.5A PAK-35J 26  KW/35 HP 45  A 60A 3P+2a2b
3 PAK-50J 30  KW/40 HP 62  A 65A 3P+2a2b
3A PAK-50H 30  KW/40 HP 62  A 75A 3P+2a2b
4 PAK-65H 37  KW/50 HP 75  A 90A 3P+2a2b
4.5 PAK-80H 45  KW/60 HP 90  A 110A 3P+2a2b
5 PAK-95H 55  KW/75 HP 110 A 110A 3P+2a2b
5A PAK-100H 55  KW/75 HP 110 A 150A 3P+2a2b
6 PAK-125H 60  KW/80 HP 125 A 170A 3P+2a2b
7 PAK-150H 75  KW/100HP 150 A 220A 3P+2a2b
9 PAK-220H 95  KW/125HP 180 A 275A 3P+2a2b
11 PAK-300H 150KW/200HP 274 A 350A 3P+2a2b
13 PAK-400H 200KW/270HP 400 A 420A 3P+3a3b
14 PAK-600H 300KW/400HP 600 A 600A 3P+3a3b
16 PAK-800H 400KW/530HP 800A 800A 3P+3a3b


(Aux) PAK-8JS22 Auxiliary Contactors   10A 2a+2b
(Aux) PAK-8JS44 Auxiliary Contactors   10A 4a+4b

NOTE:  "PAK-J Contactors (PAK-11J to PAK-50J & PAK-8JS) are also suitable for Din rail Mounting.

AUXILIARY CONTACTS FOR CONTACTORS:

HAU-2-11 Aux Contact Unit for     10A 1a+1b
  PAK-11J to PAK-50J
  & PAK-50H to PAK-95H & PAK-8JS

HAU-4-22 Aux Contact Unit for     10A 2a+2b
  PAK-11J to PAK-50J
  & PAK-50H to PAK-95H & PAK-8JS

MECHANICAL INTERLOCK FOR CONTACTORS







Type: ML-E
For PAK-12J to PAK-50J
Type: ML-C
For PAK-50H, 65H, 80H, 95H
Type: ML-D
  For PAK-100H, 125H, 150H, 220H

NO LOSS LATCHING UNITS
  For PAK-12J to 50J & PAK-50H to PAK-95HHL-B    220V  50Hz

TERMINAL COVERS FOR CONTACTORS

C-11 for For PAK-11J, PAK-12J
C-13 for For PAK-21J
C-14 for For PAK-26J to 50J
C-31 for For HAU-2-11
C-32 for For HAU-4-22

SPARE OPERATING COILS FOR "TOGAMI" CONTACTORS.

Coil voltages: 24V, 110V, 220V/230V & 415V 50Hz

For Size: 0, 0A, 0.5 PAK-11J, PAK-12J
For Size: 1 & 1.5 PAK-21J
For Size: 2 & 2.5 PAK-26J
For Size: 2.5, 2.5A & 3 PAK-35J & PAK-50J
For Size: 3A PAK-50H
For Sizes: 4, 4.5, 5 PAK-65H, PAK-80H & PAK-95H
For Size: 5A & 6 PAK-100H & PAK-125H
For Size: 7 PAK-150H
For Size: 9 PAK-220H

Spare Main Contacts Sets for "TOGAMI" Contactors.

(3 Pcs Moving Contacts + 6 Pcs Fixed Contacts)

For Model: PAK-11J PAK-12J
  PAK-21J
  PAK-26J
  PAK-35J
  PAK-50H
  PAK-65H
  PAK-80H
  PAK-100H
  PAK-125H
  PAK-150H
  PAK-220H

IMPORTANT NOTES

1.   TOGAMI pioneered the Automatic Power Distribution Equipment in 1922 which was patented worldwide.
       Basic Structure of AC Electromagnet was invented in 1924.
      The bimetal type Overload Relay was invented in 1930 and was patented worldwide.

2.   TOGAMI Overload Relays of smaller rating can be used with bigger sizes of TOGAMI Contactors.

3.   All the TOGAMI GT Overload Relays are also provided with PHASE FAILURE PROTECTION DEVICE,
       in case of failure of any one phase it will trip.

4.   The TOGAMI Contactors are most suitable for tough industrial uses like inching and plugging.
